Description
The Robot Cart adds fully automatic loading and unloading of circular saw blades on the LK Pro2 Kirschner Tipper.
Features
- Framework assembly system with servo motors
- Axes with high-precision guiding rails and roller spindles by servo controls
- Double arm system with 180° turning
- Magnetic grippers
- Ability to use Transport carts – Vollmer system (optional)
- Kirschner system < B63 up to Ø 630 mm; Vollmer system < ND 270 (optional), or;
- Kirschner system > B84 up to Ø 840 mm; Vollmer system > ND 320 (optional)
- Mandrel standard length: 320 mm (= as Vollmer)
- Complete electric and pneumatic equipment
- Off-set deposition of the brazed saw blades (avoids tooth on tooth)
- Placing and removing of intermediate plates unit (optional)
- Extension of loader to a later time (optional)
- Safety Device, Frame covered with steel plates at area of loading/unloading system with access door based on safety UVV – DIN
Specifications
| Robot Cart Saw Diameter | Ø 3.9″ to 24.8″ > Small Carts (up to 31.5″ upon request) |
| Ø 3.9″ to 33″ > Big Carts | |
| Machine dimension | Approx. 97″ W x 183″ D x 85″ H |
| Weight | Approx. 4,409 lbs |
Product brochure
