Description
The Accord is a numeric control machine center, with a fixed work table and a mobile gantry, which carries all the working units. This machine has been design to process a wide range of material such as Particle board, MDF, Plywood, Hardwood, Plastic, and light alloys.
-
Subfamily
5 Axis CNC Routers
-
Type of work
Drilling, Routing
-
X axis work area
16 ft 5.64 inch
-
Y axis work area
5 ft 6.14 inch
-
Max panel passage
1 ft 1.78 inch
-
X axis movement speed
295.28 ft/min
-
Y axis movement speed
295.28 ft/min
-
Z axis movement speed
98.43 ft/min
-
Working table
-
Working table
Pod and Rail
-
No. Of Rails
8
-
With positioning by NC
-
Vacuum cups to secure piece being processed
-
with positioning by NC
-
Clamps to secure piece being processed
-
Vacuum pump
-
No. pumps
2
-
Single capacity
300 m3/h
- Boring units 2
-
1
-
Unit
top
-
Vertical Boring Spindles
3
-
Horizontal Boring Spindles in X
0
-
Horizontal Boring Spindles in Y
0
-
2
-
Unit
top
-
Horizontal Boring Spindles in X
2
-
Horizontal Boring Spindles in Y
2
- Router Spindles 2
-
1
-
Unit
top
-
No. controlled axes
5
-
Automatic tool change
-
Liquid cooling system
-
Motor power
16.09 hp
-
r.p.m.
20000 RPM
-
2
-
Unit
top
-
No. controlled axes
3
- Grooving unit 1
-
1
-
Unit
top
-
Grooving unit
-
Unit
Fixed for Grooving in Y
-
Max. tool diameter
11.81 inch
-
r.p.m.
4500 RPM
- Horizontal electrospindle 1
-
1
-
No. outputs
2
-
with positioning by NC
- Tool magazine 2
-
1
-
No. positions
12
-
Tool
positioned on the machining head
-
2
-
No. positions
24
-
Tool
positioned at the side of the machine
-
Control system
Maestro
-
Protection structure for operating units with safety sensors
-
Safety system
Safety photocells
-
Waste chip conveyor
-
Total installed power
50 KW
