Description
- Designed to notch and drill the underside of a drawer box for mounting undermount drawer slides
- Pneumatic cutter & drill stroke by foot pedal operation.
- Cutter stroke and drill speed are adjustable for optimum finish results
- Drill will automatically position for both left and right drawer notches by activating a switch in the fence
- Machine will not cycle unless a drawer is up against the switch for safe operation
- Insert knife cutterhead with solid carbide inserts for optimum finish results and long tool life
- 2 ¼” (57mm) wide cutter allows for a wide range of undermount slides
- Comes with insert cutterhead with inserts and ¼” (6.3mm) solid carbide drill bit.
- Capable of notching up to 220 drawer boxes (both left and right) per hour.
Specifications:
| Main cutter motor | 3 HP, 3PH, 230 or 460V |
| Notch dimensions | 2 ¼” (57mm) x 0.5” high |
| Cutter diameter | 10” |
| Drill diameter | ¼” |
| Table size | 49” x 22” |
| Table height from floor | 32” |
| Dust port | 4” (670 CFM requirement) |
| Compressed air required | 90 – 100 PSI |
| Machine dimensions | 48” x 37 ¾” x 39 ¾” |
| Machine weight | 506 lbs. |
